5GHz MIMO Antenna

Features

  4.9-6.5GHz Frequency

  34dBi High Gain

  MIMO

  Dual Slant

  3 Feet Dish

Applications

  4.9/5.1/5.3/5.4/5.8/6.4 GHz ISM and UNII Band

  MIMO and 802.11n Applications

  802.11AX Applications

  Long Distance Backhaul and Point to Point Data Links

Technical Specifications

Electrical

Model

ANT4965D34P-DP

Frequency Range

4.9-5.1GHz

5.1-5.9GHz

5.9-6.5GHz

Gain( dBi)

31.5dBi

32.5dBi

34dBi

VSWR

<2.5

<2.0

<2.0

Polarization

Dual Slant (V/H or ±45°)

Isolation

>30dB

Front to Back Ratio

>40dB

Horizontal Beam width

3.5°

Vertical Beam width

3.5°

Maximum Power Per Port

50W

Impedance

50Ω

Lighting protection

DC Ground

Mechanical

Connector

2 * N Female

Antenna Size

φ0.9 m

Antenna Weight

10kg

Antenna color

white

Dish material

aluminum

Diameter of the Pole

Φ30 to φ80 mm

Operational Temperature

-40°C to +70°C (-32°F to +158°F)

Shipping Dimensions

102*101*33cm (including 2pcs Antenna)

Shipping Weight

21.4kg (including 2pcs Antenna)
